SJ MOSFET
| Product Part Name | BVDSS[V] | RDS(ON)[R] | ID[A] | Qg[nC] | Product status | Datasheet DOWN | package |
| TSA65R190S3 | 650 | 0.19 | 20 | 36.5 | Matured |  |
TO-3P |
| TSF65R190S2 | 650 | 0.19 | 20 | 36.5 | Matured | |
TO-220F |
| TSF60R190S2 | 600 | 0.19 | 20 | 36.5 | Matured | |
TO-220F |
| TSF65R360S2 | 650 | 0.38 | 13 | 43 | Matured | |
TO-220F |
| TSK80R380S1 | 800 | 0.38 | 13.6 | 17.5 | Matured | |
TO-247 |
| TSP80R380S1 | 800 | 0.38 | 13.6 | 17.5 | Matured | |
TO-220 |
| TSF80R380S1 | 800 | 0.38 | 13.6 | 17.5 | Matured | |
TO-220F |
| TSD80R500S1 | 800 | 0.5 | 10.5 | 13 | Matured | |
TO-252 |
| TSP80R500S1 | 800 | 0.5 | 10.5 | 13 | Matured | |
TO-220 |
| TSF80R500S1 | 800 | 0.5 | 10.5 | 13 | Matured | |
TO-220F |
| TSP80R600S1 | 800 | 0.6 | 9 | 12 | Matured | |
TO-220 |
| TSF80R600S1 | 800 | 0.6 | 9 | 12 | Matured | |
TO-220F |
| TSD80R850S1 | 800 | 0.85 | 6.6 | 9.5 | Matured | |
TO-252 |
| TSF80R850S1 | 800 | 0.85 | 6.6 | 9.5 | Matured | |
TO-220F |
| TSD80R1K3S1 | 800 | 1.3 | 4.4 | 6 | Matured | |
TO-252 |
| TSP80R1K3S1 | 800 | 1.3 | 4.4 | 6 | Matured | |
TO-220 |
| TSF80R1K3S1 | 800 | 1.3 | 4.4 | 6 | Matured | |
TO-220F |
| TSP70R210S1 | 700 | 0.21 | 20 | 70 | Matured | |
TO-220 |
| TSF70R210S1 | 700 | 0.21 | 20 | 70 | Matured | |
TO-220F |
| TSP70R340S1 | 700 | 0.34 | 15 | 43 | Matured | |
TO-220 |
